Mossy Oak Camo Custom
$1,280.00
Short Description:
(1) SK6805/LC8805B-2020 RGB LED Strip use 2.0MM*2.0MM LC8805B IC inside 5mAx 3chips RGB SMD led to be the light source , white FPCB led strips,each led programmable and cuttable.
(2) Single-flow, gradient, chase, scan and other full-color effects.
(3) Splicing to achieve text movement and video animation and other dynamic effects.
(4) Can be bend and cut, can achieve a certain curvature and length of the modeling screen.
(5) 1 LED 1 IC, individual controlled, can be made into high-density high-definition display.
Product Specifications:
| Product Name | SK6805/LC8805B-2020 RGB LED Strip |
| LED type | 2020 SMD LED |
| IC type | LC8805B |
| Emitting color | Digital RGB |
| LED Q’ty | 96led/m |
| Pixel Q’ty | 96pixel/m |
| LED View angle | 120 Degree |
| PCB Color | White/Black |
| IP Rating | IP20, IP65, IP67, IP68. |
| Length/Roll | 5M/Roll, strip length can be customized |
| Working Voltage | DC5V |
| Certification: | CE, EMC, FCC, LVD, RoHS |
| CRI (Ra>): | 80 |
| Warranty(Year) | 2-Years |
|
Model |
LED Qty |
IC Qty |
Voltage |
Max Power |
Gray Scale |
Color |
Width |
|
LC-8805B96XM4X-5V |
96 |
96 |
5V |
9.6W/M |
256 |
Digital RGB |
4mm |
Application:
It is widely used in decoration and lighting of buildings, bridges, roads, gardens, courtyards, floors,ceilings, furniture, cars, ponds, advertisements, signs, signs and so on,which also has a great advantage in advertising, decoration, construction, commerce, gifts and other markets.
LED Strip Connection Diagram:
NOTE:
1. The AC wiring must be connected to the ground wire to prevent electric shock.
2. The overload current of the main wire of the LED Strip is the sum of the currents of the sub-wires, so in actual engineering applications, the model of the main wire should be appropriately increased to prevent the wire from overheating and accidents.
3.The specification is only for regular quotation products, specific products have specified parameters, which are not within the scope of this specification.
Packaging:
5m per roll, one roll in one package bag, Anti-static bags+Neutral packing carton box.
Shipping:
lead time: normally in 7-10days, after receiving the payment.
samples are available, which can be delivered in 3-5days once payment received.
Ship way: Door to Door express, by air or sea.
Shipping port: Shenzhen, Mainland China
Our Services:
24 hours online service.
Well-trained and experienced staffs to answer all your enquire.
Customized design,ODM/OEM Customized Service are available.
Fast response to your inquiry and feedback.
Professional after-sales service.
Warranty:
1. The product have good quality and have been tested before shipment.
2. We have 2year and 3 year warranty for different kinds of led products.
FAQ
Q: Why customer choose us?
A:a.Factory manufacturer,we can control the production process ,all our products have quality assurance, higher cost-effective and Fast delivery.
b.OEM/ODM Service: we are factory manufacturer and can provide OEM/ODM,customized service to meet customers` different demand.
c.Professional in LED: our factory team has 10 years experience in the area of the digital led strip works.
d.Quality Assurance: all our products have to be 100% aged and QC test before delivery.
Q:Can I have sample(s) to test?
A: Yes,we are pleased to supply samples to test and check quality,mixed sample order is available. free samples is also acceptable, but The freight is paid by the buyer.
Q:What’s the lead time?
A:Usually the goods can be shipped with1 week, the customized led products takes more time according to detailed products.
Q: How to order from you and how to pay?
A:If you need any led products, you can send us the email or inquiry, then we will answer you in time and send you PI with payment way, we are the factory not trade company, so we need to produce according to each order for you.
Q: What certificate you can offer?
A:Usually CE and RoHs,others UL certification we can offer too based on your need.
10.Our Certificates
LED Strip Factory Picture
Office Factory Picture
